Cylinders - Locking Gas - TDX SP/SP-GT - Before 3/5/07

Print this page

Click to Enlarge

Item

Part/Kit

Part/Kit Description

Qty/Pkg

Qty/Asbly

MSRP

View Parts Notes

1144661

Cylinder, Locking Gas

$427.00

Create/add to Wishlist

1144655

Cylinder, Locking Gas

$415.00

Create/add to Wishlist

1145053

Item	Part/Kit Description	Qty/Pkg	Qty/Asbly
3	Boot - Right	1	1
4	Tie Wrap (11-1/2" L)	1	1
5	NLA - Screw, Socket Head Cap w/ Patch (1/4-20 x 1")	1	2
6	Plate	1	1
7	NLA - Spacer (1/4 x 3/8 x 3/16")	1	2
8	Plate, Boot Mounting	1	1
9	Screw, Shoulder Hex Socket Head (5/16" x 2-1/2", 1/4-20)	1	1
10	Locknut (1/4-20)	1	1

Kit, Locking Gas Cylinder Mounting Hardware - Right

$72.00

Create/add to Wishlist

1145054

Item	Part/Kit Description	Qty/Pkg	Qty/Asbly
3	Boot - Left	1	1
4	Tie Wrap (11-1/2" L)	1	1
5	NLA - Screw, Socket Head Cap w/ Patch (1/4-20 x 1")	1	2
6	Plate	1	1
7	NLA - Spacer (1/4 x 3/8 x 3/16")	1	2
8	Plate, Boot Mounting	1	1
9	Screw, Shoulder Hex Socket Head (5/16" x 2-1/2", 1/4-20)	1	1
10	Locknut (1/4-20)	1	1

Kit, Locking Gas Cylinder Mounting Hardware - Left

$72.00

Create/add to Wishlist

Assembly Part Notes

Note Code	Definition
A	Includes items 3-10
B	Used for 300 Lb. User Weight Limit
C	Used for 400 Lb. User Weight Limit

Catalog Literature

Parts Books for TDX®SP/SP-GT/SR
