Electronics - MK5 SAC & Hardware (Before 1/06/06)

Print this page

Click to Enlarge

Item

Part/Kit

Part/Kit Description

Qty/Pkg

Qty/Asbly

MSRP

View Parts Notes

1049593

Item	Part/Kit Description	Qty/Pkg	Qty/Asbly
4	NLA - Half Clamp, Threaded Holes	1	1
5	Half Clamp, Non-Threaded Holes	1	1
6	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
7	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
8	Plate, Mounting	1	1
2	NLA - Half Clamp, Threaded Holes	1	1
3	Half Clamp, Non-Threaded Holes	1	1
4	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
5	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
6	Plate, Mounting	1	1
2	NLA - Half Clamp, Threaded Holes	1	1
3	Half Clamp, Non-Threaded Holes	1	1
4	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
5	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
6	Plate, Mounting	1	1
1	NLA - Half Clamp, Threaded Holes	1	1
2	Half Clamp, Non-Threaded Holes	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
4	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
5	Plate, Mounting	1	1
2	NLA - Half Clamp, Threaded Holes	1	1
3	Half Clamp, Non-Threaded Holes	1	1
4	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
5	Plate, Mounting	1	1
6	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
2	NLA - Half Clamp, Threaded Holes	1	1
3	Half Clamp, Non-Threaded Holes	1	1
4	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
5	Plate, Mounting	1	1
6	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
1	NLA - Half Clamp, Threaded Holes	1	1
2	Half Clamp, Non-Threaded Holes	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
4	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
5	Plate, Mounting	1	1
1	NLA - Half Clamp, Threaded Holes	1	1
2	Half Clamp, Non-Threaded Holes	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
4	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
5	Plate, Mounting	1	1
2	NLA - Half Clamp, Threaded Holes	1	1
3	Half Clamp, Non-Threaded Holes	1	1
4	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
5	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
6	Plate, Mounting	1	1
1	NLA - Half Clamp, Threaded Holes	1	1
2	Half Clamp, Non-Threaded Holes	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
4	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
5	Plate, Mounting	1	1
2	Half Clamp, Non-Threaded Holes	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
4	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
5	Plate, Mounting	1	1
6	NLA - Half Clamp, Threaded Holes	1	1
2	NLA - Half Clamp, Threaded Holes	1	1
3	Half Clamp, Non-Threaded Holes	1	1
4	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
5	Plate, Mounting	1	1
6	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
2	NLA - Half Clamp, Threaded Holes	1	1
3	Half Clamp, Non-Threaded Holes	1	1
4	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
5	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
2	NLA - Half Clamp, Threaded Holes	1	1
3	Half Clamp, Non-Threaded Holes	1	1
4	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
5	Plate, Mounting	1	1
6	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
6	Plate, Mounting	1	1
1	NLA - Half Clamp, Threaded Holes	1	1
1	NLA - Half Clamp, Threaded Holes	1	1
2	Half Clamp, Non-Threaded Holes	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
6	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
7	Plate, Mounting	1	1
1	NLA - Half Clamp, Threaded Holes	1	1
2	Half Clamp, Non-Threaded Holes	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
4	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
5	Plate, Mounting	1	1
1	NLA - Half Clamp, Threaded Holes	1	1
2	Half Clamp, Non-Threaded Holes	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
6	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
7	Plate, Mounting	1	1
5	Plate, Mounting	1	1
2	Half Clamp, Non-Threaded Holes	1	1
1	NLA - Half Clamp, Threaded Holes	1	1
2	Half Clamp, Non-Threaded Holes	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
6	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
7	Plate, Mounting	1	1
1	NLA - Half Clamp, Threaded Holes	1	1
2	Half Clamp, Non-Threaded Holes	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
6	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
7	Plate, Mounting	1	1
1	NLA - Half Clamp, Threaded Holes	1	1
2	Half Clamp, Non-Threaded Holes	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
6	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
7	Plate, Mounting	1	1
1	NLA - Half Clamp, Threaded Holes	1	1
2	Half Clamp, Non-Threaded Holes	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
6	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
7	Plate, Mounting	1	1
4	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
5	Plate, Mounting	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
1	NLA - Half Clamp, Threaded Holes	1	1
2	Half Clamp, Non-Threaded Holes	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
1	NLA - Half Clamp, Threaded Holes	1	1
2	Half Clamp, Non-Threaded Holes	1	1
3	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
6	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
7	Plate, Mounting	1	1
4	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2
2	NLA - Half Clamp, Threaded Holes	1	1
3	Half Clamp, Non-Threaded Holes	1	1
4	NLA - Screw, Hex Head (1/4-20 x 1-1/8")	1	2
5	Plate, Mounting	1	1
6	Screw, Phillips Pan Head (#4-40 x 3/8")	1	2

Kit, SNP/DI, MK5 SAC, 4WSB, S4WSB, GTAM, AUX12M6, AUX34M6 Mtg. Hdwr.

$52.00

A ,C

Create/add to Wishlist

1115730

NLA - Control, MK5 SAC

N/A

Create/add to Wishlist

1119418

Cable, Auxiliary Power

Create/add to Wishlist

Assembly Part Notes

Note Code	Definition
A	Includes items 2-6
B	On 1/06/06 the MK5 SAC was discontinued. As a replacement, refer to the MK5 TAC and Hardware category.
C	As of 5/22/07 the Mounting Plate holes and the orientation of the Hardware was revised to attach the electronics closer to the chair. The Mounting Hardware Kit is backward compatible.
