Item	Part/Kit	Part/Kit Description	Qty/Pkg	Qty/Asbly	MSRP	View Parts Notes
1	1087626	NLA - Support, Seat Frame	1	1	N/A	B	Create/add to Wishlist Create/add to Wishlist New Wishlist Description
1	1121053	NLA - Support, Seat Frame and Spacer Plate with Hardware	1	1	N/A	C	Create/add to Wishlist Create/add to Wishlist New Wishlist Description
2	1071237	Plug Button, Square, Black (1")	1	2			Create/add to Wishlist Create/add to Wishlist New Wishlist Description
3	0055800	NLA - Washer, Nylon (7/16 x 3/4 x 3/32")	1	4	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
4	0060300	NLA - Bushing, Bronze (5/16 x 7/16 x 1-1/4")	1	2	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
5	1070412	NLA - Screw, Hex Head (5/16-18 x 2-1/4")	1	2	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
6	1026158	Locknut (5/16-18)	1	2	$9.20		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
7	1025704	Washer, Flat (5/16 x 5/8 x 1/16")	1	4	$7.20		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
8	1106540	NLA - Hardware, Seat Frame Support Mounting	1	1	N/A	A	Create/add to Wishlist Create/add to Wishlist New Wishlist Description

Note Code	Definition
A	Includes items 2-7
B	Seat support frame revised 2/17/03 to accommodate a spacer plate for 12"-15" wide seat frames. For 12"-15" wide PTO models made before 2/17/03 order Item 1 part number 1121053. The revised support frame is still used for all 16"-22" wide PTO models.
C	Used for 12"-15" wide PTO models made before 2/17/03. Spacer plate and hardware included. Spacer plate can be found on the A.S.B.A. Seat Mounting Hardware page.
