Accessories - Torso Support - Adjustable

Print this page

Adjustable Torso Support

Click to Enlarge

Item	Part/Kit	Part/Kit Description	Qty/Pkg	Qty/Asbly	MSRP	View Parts Notes
1	88804529X040	NLA - Pad, Headrest	1	1	N/A	A	Create/add to Wishlist Create/add to Wishlist New Wishlist Description
2	1028481	NLA - Screw, Socket Head (1/4-20 x 1/2")	1	2	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
3	88804529X043	NLA - Cover Torso Bracket	1	1	N/A	A	Create/add to Wishlist Create/add to Wishlist New Wishlist Description
4	1028758	NLA - Bracket, Clamp, Black - Right	1	1	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
4	1028759	NLA - Bracket, Clamp, Black - Left	1	1	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
5	03018X041	NLA - Bracket, Pad Support, Chrome	1	1	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
6	1031026	Screw w/ Lug (5/16-24 x 1-3/8")	1	1	$10.00		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
7	7930330	NLA - Locknut (5/16-24)	25	1	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
8	03018X016	NLA - Bracket, Support, Chrome	1	1	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
9	7930328	NLA - Package, Screw, Phillips Pan Head (#10-32 x 11/16")	25	2	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
10	03018X012	NLA - Rod, Support w/ Guide Tube	1	1	N/A		Create/add to Wishlist Create/add to Wishlist New Wishlist Description
11	8881044753	NLA - Torso Support Assembly, Adjustable, Non-Recliner (Pair)	2	1	N/A	A	Create/add to Wishlist Create/add to Wishlist New Wishlist Description
11	8881044755	NLA - Torso Support Assembly, Adjustable, Recliner (Pair)	2	1	N/A	A	Create/add to Wishlist Create/add to Wishlist New Wishlist Description
	1023610	NLA - Instruction Sheet	1	1	N/A	B ,C	Create/add to Wishlist Create/add to Wishlist New Wishlist Description

Assembly Part Notes

Note Code	Definition
A	Specify color when ordering, see Frame Finishes, Touch-Up Paints, Upholstery Options and Accent Packages page.
B	Not Shown
C	Item is no longer available from the Invacare Service Parts Department. Refer to the Invacare Website under "Product Literature Search". Enter the part number in the "Keywords" field and download a free PDF version copy.

Catalog Literature

Parts Books for Action Series Arrow® 4M900/5M900 Ranger X™ M3900 Ranger II™ RM900
