EQUIPMENT US Site

2

1113572

Footplate, Adjustable Angle, Medium, Black (4-1/4" W x 8" L)

1

$80.00

B ,F

Create/add to Wishlist

2

1113573

Footplate, Adjustable Angle, Large, Black (5-1/4" W x 8" L)

1

$79.00

C ,F

Create/add to Wishlist

2

1113574

Footplate, Adjustable Angle, Extra Large, Black (6-1/4" W x 8" L)

1

$80.00

D ,F

Create/add to Wishlist

3

1058517

Clamp, Footplate

1

$13.50

Create/add to Wishlist

4

1057855

Tube, Pivot and Slide, Straight, Steel, Black (9-7/8" L)

1

$25.00

Create/add to Wishlist

4

1057856

Tube, Pivot/Slide, Straight, Steel, Black (11-7/8" L)

1

$25.00

Create/add to Wishlist

4

1121135

Tube, Pivot/Slide, Straight, Steel, Black (13-7/8" L)

1

$31.00

Create/add to Wishlist

4

1091745

NLA - Tube, Pivot/Slide, Straight, Steel, Chrome (13-7/8" L)

1

N/A

E

Create/add to Wishlist

5

1048816

Screw, Nylon Adjustment (1/2-13 x 7/8")

1

$10.00

Create/add to Wishlist

6

1052102

Hinge, Footplate - Right

1

$57.00

Create/add to Wishlist

6

1052103

Hinge, Footplate - Left

1

$57.00

Create/add to Wishlist

7

1029545

Screw, Socket Flat Head (1/4-20 x 3/4")

1

2

$9.20

Create/add to Wishlist

8

7930321

NLA Package, Screw, Socket Button Head (1/4-20 x 1-7/8")

25

1

N/A

Create/add to Wishlist

9

1026900

Washer (1/4 x 23/32 x 1/16")

1

$1.20

Create/add to Wishlist

10

7930313

Package, Washer, Nylon (5/16 x 7/8 x 1/8")

25

1

$44.00

Create/add to Wishlist

11

1036435

Washer, Nylon (1/4 x 7/8 x 1/32")

1

$10.00

Create/add to Wishlist

12

1025457

Spacer, Coved (1/4 x 3/4 x 11/32")

1

$8.00

Create/add to Wishlist

13

1026099

Spacer, Coved (1/4 x 11/16 x 1/2")

1

$8.00

Create/add to Wishlist

14

1026907

Washer (1/4 x 1/2 x 1/16")

1

$7.20

Create/add to Wishlist

15

7930333

Locknut (1/4-20)

25

1

$44.00

Create/add to Wishlist

16

1082686

Nut, Barrel, Hex Head (1/4-20 x 11/16")

1

2

$9.20

Create/add to Wishlist

See Chart

Added to Cart

Rigging Types	90 and 70MFX Footplate Assembly w/o Pivot/SlideTube	60, 60MFX, 70 PW93, PW93E AT5544, P904 (9-7/8" Tube)	60, 60MFX, 70 PW93, PW93E AT5544, P904 (11-7/8" Tube)	60, 60MFX, 70 PW93, PW93E AT5544, P904 (13-7/8" Tube)	PAS4A and PAL4A (13-7/8" Tube)
12-13" W, Right (4-1/4" Footplate)	1060436- NLA	1060442 MSRP: $137.00	N/A	N/A	N/A
12-13" W, Left (4-1/4" Footplate)	1060437	1060443 MSRP: $137.00	N/A	N/A	N/A
14-15" W, Right (5-1/4" Footplate)	1060438 MSRP: $114.00	1060444 MSRP: $113.00	1062758 MSRP: $97.00	1121138- NLA	1091775- NLA
14-15" W, Left (5-1/4" Footplate)	1060439 MSRP: $114.00	1060445 MSRP: $113.00	1062759 MSRP: $97.00	1121139- NLA	1091776- NLA
16" and Wider, Right (6-1/4" Footplate)	1062570 MSRP: $114.00	1062756 MSRP: $115.00	1062760 MSRP: $109.00	1121140 MSRP: $141.00	1091777- NLA
16" and Wider, Left (6-1/4" Footplate)	1062571 MSRP: $114.00	1062757 MSRP: $115.00	1062761 MSRP: $109.00	1121141 MSRP: $141.00	1091778- NLA

Create/add to Wishlist

Pivot/ Slide Tube with Footplate Assemblies

N/A

Note Code	Definition
A	Includes Items 2 thru 16.
B	For 12-13" wide chairs
C	For 14-15" wide chairs
D	For 16" and wider chairs
E	For PAS4A/PAL4A only.
F	The footplate design was revised 9/2/2008 with rounder corners and accessory holes changed from 8 to 4. Recommended to replace in pairs to match sides.

Maximum of three products are allowed for comparison.

Maximum of three products are allowed for comparison.

Maximum of three products are allowed for comparison.

Front Riggings - Adjustable Angle Footplate Assemblies- AT5543
