Motors - GB Connector Covers

Print this page

Click to Enlarge

Item

Part/Kit

Part/Kit Description

Qty/Pkg

Qty/Asbly

MSRP

View Parts Notes

1141670

Item	Part/Kit Description	Qty/Pkg	Qty/Asbly
2	Bracket, Cover, Connector, Black - Right	1	1
3	Bracket, Cover, Connector, Top, Black - Right	1	1
4	NLA - Screw, Phillips Pan Head w/ Patch (#10-32 x 3/8")	1	4
5	NLA - Washer, Plain (3/16 x 1/2 x 1/16")	1	2
	Sheet, Instruction	1	1
2	Bracket, Cover, Connector, Black - Right	1	1
3	Bracket, Cover, Connector, Top, Black - Right	1	1
4	NLA - Screw, Phillips Pan Head w/ Patch (#10-32 x 3/8")	1	4
5	NLA - Washer, Plain (3/16 x 1/2 x 1/16")	1	2
	Sheet, Instruction	1	1

NLA - GB Connector Cover w/o Wheel Lock Assembly - Right

N/A

Create/add to Wishlist

1141671

Item	Part/Kit Description	Qty/Pkg	Qty/Asbly
2	Bracket, Cover, Connector, Black - Left	1	1
3	Bracket, Cover, Connector, Top, Black - Left	1	1
4	NLA - Screw, Phillips Pan Head w/ Patch (#10-32 x 3/8")	1	4
5	NLA - Washer, Plain (3/16 x 1/2 x 1/16")	1	2
	Sheet, Instruction	1	1
2	Bracket, Cover, Connector, Black - Left	1	1
3	Bracket, Cover, Connector, Top, Black - Left	1	1
4	NLA - Screw, Phillips Pan Head w/ Patch (#10-32 x 3/8")	1	4
5	NLA - Washer, Plain (3/16 x 1/2 x 1/16")	1	2
	Sheet, Instruction	1	1

NLA - GB Connector Cover w/o Wheel Lock Assembly - Left

N/A

Create/add to Wishlist

1141672

Item	Part/Kit Description	Qty/Pkg	Qty/Asbly
2	Bracket, Cover, Connector, Black - Right	1	1
4	NLA - Screw, Phillips Pan Head w/ Patch (#10-32 x 3/8")	1	2
5	NLA - Washer, Plain (3/16 x 1/2 x 1/16")	1	2
	Sheet, Instruction	1	1
2	Bracket, Cover, Connector, Black - Right	1	1
4	NLA - Screw, Phillips Pan Head w/ Patch (#10-32 x 3/8")	1	2
5	NLA - Washer, Plain (3/16 x 1/2 x 1/16")	1	2
	Sheet, Instruction	1	1

GB Connector Cover w/ Wheel Lock Assembly - Right

Create/add to Wishlist

1141673

Item	Part/Kit Description	Qty/Pkg	Qty/Asbly
2	Bracket, Cover, Connector, Black - Left	1	1
4	NLA - Screw, Phillips Pan Head w/ Patch (#10-32 x 3/8")	1	2
5	NLA - Washer, Plain (3/16 x 1/2 x 1/16")	1	2
	Sheet, Instruction	1	1
2	Bracket, Cover, Connector, Black - Left	1	1
4	NLA - Screw, Phillips Pan Head w/ Patch (#10-32 x 3/8")	1	2
5	NLA - Washer, Plain (3/16 x 1/2 x 1/16")	1	2
	Sheet, Instruction	1	1

GB Connector Cover w/ Wheel Lock Assembly - Left

Create/add to Wishlist

Assembly Part Notes

Note Code	Definition
A	Includes items 2-5 and instruction sheet.
B	Includes items 2, 4, 5 and instruction sheet.

Catalog Literature

Parts Books for TDX®3 TDX®3 SE TDX®4 TDX®5
