1

1020454

Handrim, Dual Drive

1

$174.00

C

Create/add to Wishlist

1

1020455

Handrim, Dual Drive

1

D

Create/add to Wishlist

2

1058164

NLA - Wheel Assembly w/ Chrome Handrim, Composite, DTM Tire, Black (24")

1

N/A

Create/add to Wishlist

2

1091816

Wheel Assembly w/ Clear Anodized Handrim, Composite, Corded Urethane (24")

1

$250.00

E

Create/add to Wishlist

3

47324X011

Bushing, Pivot (5/16 x 7/8 x 3/4")

1

2

Create/add to Wishlist

4

11232X009

Bolt, Lug (5/16-24 x 1-3/8")

1

2

$10.00

Create/add to Wishlist

5

1107321

Nut, Low Cap (5/16"-24)

1

2

$10.00

Create/add to Wishlist

6

48323X013

Washer (5/8 x 7/8 x 1/8")

1

2

$10.00

D

Create/add to Wishlist

6

47183X018

Spacer (5/8 x 7/8 x 1/2")

1

2

C

Create/add to Wishlist

7

40117X006

Bearing (5/8")

1

4

$11.00

Create/add to Wishlist

8

57769X000

NLA - Cup, Bearing

1

4

N/A

Create/add to Wishlist

9

04604X030

NLA - Bracket, Chrome

1

2

N/A

Create/add to Wishlist

10

1029501

Plug Button, Black (1")

1

2

$7.20

Create/add to Wishlist

11

48323X013

Washer (5/8 x 7/8 x 1/8")

1

2

$10.00

Create/add to Wishlist

12

60030X000

Locknut (5/8-18)

1

2

$10.00

Create/add to Wishlist

13

1019101

Screw, Hex Head (1/4-28 x 1-1/2")

1

2

$10.00

Create/add to Wishlist

14

40157X000

Washer, Steel (11/32 x 5/8 x 3/64")

1

4

$8.00

Create/add to Wishlist

15

60320X000

Locknut (1/4-28)

1

2

$10.00

Create/add to Wishlist

16

1019105

Scissor Assembly (14 - 15" W)

1

Create/add to Wishlist

16

1019106

Scissor Assembly (18 - 19" W)

1

$122.00

Create/add to Wishlist

16

1048655

Scissor Assembly (20" W)

1

$201.00

Create/add to Wishlist

17

1020710

NLA - Axle, Drive

1

N/A

D

Create/add to Wishlist

17

1020709

NLA - Axle, Drive

1

N/A

C

Create/add to Wishlist

18

1016979

Spacer, Wheel Lock Shoe (2-7/16")

1

$11.00

Create/add to Wishlist

19

1008438

Screw, Set Socket Cup Point (#8-32 x 3/16")

1

2

$10.00

Create/add to Wishlist

20

1058166

NLA - Wheel Assembly w/ Drive Axle, Composite, DTM Tire, Black (24")

1

2

N/A

D

Create/add to Wishlist

20

1108394

Wheel Assembly w/ Drive Axle, Composite, Urethane (24")

1

2

D

Create/add to Wishlist

20

1025396

NLA - Wheel Assembly w/ Drive Axle, Composite, Pneumatic Mag (24")

1

2

N/A

D

Create/add to Wishlist

20

1036189

NLA - Wheel Assembly w/ Drive Axle, Composite, Pneumatic Mag w/ Flat Free Insert (24")

1

2

N/A

D

Create/add to Wishlist

20

1058165

NLA - Wheel Assembly w/ Drive Axle, Composite, DTM Tire, Black (24")

1

2

N/A

C

Create/add to Wishlist

20

1091817

Wheel Assembly w/ Drive Axle, Composite, Corded Urethane (24")

1

2

$241.00

E

Create/add to Wishlist

20

1025397

NLA - Wheel Assembly w/ Drive Axle, Composite, Pneumatic Mag (24")

1

2

N/A

C

Create/add to Wishlist

20

1042075

NLA - Wheel Assembly w/ Drive Axle, Composite, Pneumatic Mag w/ Flat Free Insert (24")

1

2

N/A

Create/add to Wishlist

See Chart

Added to Cart

Chair Width	Permanent Arms Hemi	Removable Arms Hemi	Permanent Arms Adult	Removable Arms Adult
16"	1074442	1074443	1042102- NLA	1042080- NLA
18"	1042102- NLA	1042080- NLA	1042103- NLA	1042081- NLA
20"	N/A	1074424	N/A	1074435

Create/add to Wishlist

#21 - One Arm Drive, Pneumatic with Flat Free Insert

N/A

See Chart

Added to Cart

Chair Width	Permanent Arms Hemi	Removable Arms Hemi	Permanent Arms Adult	Removable Arms Adult
16"	1074438	1074439	1042098- NLA	1042076- NLA
18"	1042098- NLA	1042076- NLA	1042099- NLA	1042077- NLA
20"	N/A	1074416	N/A	1074425

Create/add to Wishlist

#21 - One Arm Drive, DTM Tires

N/A

See Chart

Added to Cart

Chair Width	Permanent Arms Hemi	Removable Arms Hemi	Permanent Arms Adult	Removable Arms Adult
16"	1074440	1074441	1042100- NLA	1042078- NLA
18"	1042100- NLA	1042078- NLA	1042101- NLA	1042079- NLA
20"	N/A	1074417	N/A	1074434

Create/add to Wishlist

#21 - One Arm Drive, Pneumatic Tires

N/A

Note Code	Definition
A	Includes items 1-20 and Instruction Sheet
B	Not Shown
C	Removable Arm Chairs
D	Permanent Arm Chairs
E	Non-Corded Tire replaced with a Corded Tire as of 11/16/09. It is recommended that both sides of the Wheel Assemblies be ordered for chairs manufactured before 11/16/09.
